Fujitsu PRIMERGY RX1330 M4 User Manual

100 Operating Manual RX1330 M4
Technical data
Noise level (depending on the configuration)
The acoustic noise values are depending on the system configuration.
Electrical data: 300 W (standard PSU)
Electrical data: 450 W (hot-plug PSU)
Standard configuration
SATA systems
(4x 2.5-inch HDD/SSD,
standard PSU)
SAS systems
(10x 2.5-inch SAS HDD,
redundant PSU)
Sound power level
L
WAd
(ISO 9296)
4.2 B (standby)
4.2 B (operation)
5.8 B (standby)
5.8 B (operation)
Sound pressure
level at adjacent
workstation L
pAm
(ISO 9296)
26 dB (A) (standby)
26 dB (A) (operation)
40 dB (A) (standby)
40 dB (A) (operation)
Declared noise
emission
according to ISO
9296
Standby
Operating (ISO 7779)
ETSI 300 753 Class 3.1
Rated voltage range 100 - 240 V
Rated frequency range 50 Hz - 60 Hz
Max. rated current 3.0 - 1.5 A (100 - 240 V)
Rated voltage range 100 - 240 V
Rated frequency range 50 Hz - 60 Hz
Max. rated current 4.5 - 2.0 A (100 - 240 V)

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
