RX1330 M4 Operating Manual 99
Technical data
Dimension/Weight
Ventilation clearance
There must be a clearance of at least 200 mm in front of and behind the server
to ensure adequate ventilation of the subsystem.
Ambient conditions
Rack (W x D x H) 482.6 mm (bezel) / 435,4 mm (body) x 610.1 mm x
42.85 mm
Height unit rack 1 HU
Installation depth in
rack
558,75 mm
Weight 8.3 - 13.5 kg
Weight notes Weight may vary depending on actual configuration
Rack mounting kit Rack mounting kit as option
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 10 °C ... 35 °C
5 °C ... 40 °C (with Cool-safe® ATD 40 °C)
5 °C ... 45°C (with Cool-safe® ATD 45 °C)
Transport (2K2) -25°C ... 60°C
Humidity 10% ... 85% (non condensing)
Condensation during operation must be avoided!

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
