50 Options Guide U41629-J-Z156-2-76
Conversion standard PS to hot-plug PS
Figure 29: Loosening the screws
Ê Remove the five screws (1) which attach the adapter plate of the standard
power supply to the housing.
Figure 30: Taking out the standard power supply
Ê Slide the standard power supply somewhat toward the inside (1) to detach it
from the brackets in the side cover and take it out toward the side (2).
1
1
2
