Fujitsu PRIMERGY TX150 S4

U41629-J-Z156-2-76 Options Guide 71
Completion Rack model
Figure 50: Attaching the rack front cover
Ê Attach the rack front cover from the front (1).
Ê Attach the rack front cover using two screws on each side (2).
2
2
1
