Fujitsu PRIMERGY TX150 S4

82 Options Guide U41629-J-Z156-2-76
Cabling Appendix
Figure 59: Cabling SATA version with additional SATA RAID controller
Cable prefix: T26139-
Power SCSI IDE/FD Data
Legend:
SATA HD0 SATA HD1 SATA HD2 SATA HD3
1" HDD
SATA backplane
CD/DVD
Floppy
Tape
Floppy
Operating panel
USB
IDTEMP
Y3859-V11
Y1248-V8
Y3730-V502
Y2603-V7
Intrusion sw.
Y3736-V1
Y3718-V508
Y3728-V1
P9
P3
P2
P4
P5
P6
X6
X10
X12
System
P1
P8
Power supply
SATA3
SATA1
SATA4
SATA2
SATA LED
SCSI controller
SATA
fan
Tape
Intrusion sw.
SATA RAID
controller
Y3963-V1
USB-B for tape
Y3904-V101
