24 Operating Manual
TX2560 M2 / RX2560 M2
Functional overview
Interfaces
Onboard or integrated controllers
USB 5 x USB 3.0 (2 x front, 2 x rear, 1 x internal)
2 x USB 2.0 (rear)
Graphics (15-pin) 2 x VGA (thereof 1x front optional)
Serial 1 (9-pin) 1 x serial RS-232-C, usable for iRMC S4 or system
or shared (optional)
LAN / Ethernet Dynamic LoM (LAN on Motherboard) option:
2 x 1 GBit/s (RJ45)
4 x 1 GBit/s (RJ45)
2 x 10 GBit/s (RJ45)
2 x 10 GBit/s (SFP+)
Management LAN
(RJ45)
1 x dedicated management LAN port for iRMC S4
(10/100/1000 Mbit/s). Management LAN traffic can
be switched to shared onboard converged network
adapter.
RAID controller Two 4 port internal 6G SATA for HDDs with RAID
level 0/1/10.
For additional RAID controller options are described
under "RAID controllers (expansion cards)" on
page 25
SATA controller Intel
®
C612, 1 x SATA channel for ODD
LAN Controller Emulex converged network adapter, 4x 10 Gbit/s
PXE-Boot via LAN from PXE server, iSCSI boot (also
diskless).
