TX2560 M2 / RX2560 M2
Operating Manual 25
RAID controllers (expansion cards)
Slots
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V1.2 compliant
(option)
RAID controllers RAID 5/6 Ctrl., HDD SAS up to 12 Gbit/s, LSI, 8 ports
ext. RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB Cache,
Optional FBU (based on LSI SAS3108).
RAID 5/6 Ctrl., HDD SAS up to 12 Gbit/s, 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB Cache,
Optional FBU (based on LSI SAS3108).
RAID 0/1 Ctrl., SAS/SATA 6 Gb, 8 ports int. RAID
level: 0, 1, 10, No FBU support.
Standard
PCI-Express - Gen3 x16 3 x full height
PCI-Express - Gen3 x8 3 x full height
Expansion with riser module 1
PCI-Express - Gen3 x8 1 x full height
PCI-Express - Gen3 x4 2 x full height
Expansion with riser module 2
PCI-Express - Gen3 x8 1 x full height
PCI-Express - Gen3 x4 2 x full height
Slot notes Each PCIe riser card occupies one
PCIe Gen3 x16 slot of standard.
With CPU1 only 2x PCIe x8 and 1x PCIe x16
slots are supported.
