Functional overview
Drive bays
Operating Panel
Hard disk bay
configuration
12x 3.5-inch hot-plug SAS HDD or 32x 2.5-inch hot-
plug SAS HDD/SSD optional
Accessible drive bays 3 x 5.25/1.6-inch for ODD or tape drive
Operating buttons On/off button
Reset button
NMI button
ID button
Status LEDs Global error indicator (orange)
ID indicator (blue)
HDD activity indicator (green)
Power-on indicator (green)
AC connected indicator (green)
CSS indicator (orange)
Status LEDs at system
rear side:
Global error / CSS / ID indicator (orange / orange /
blue)
LAN connection indicator (green)
LAN speed indicator (green / yellow)
