28 Operating Manual
TX2560 M2 / RX2560 M2
Noise level (depending on the configuration)
The acoustic noise values are depending on the system configuration.
Electrical data: 450 W Platinum
Electrical data: 800 W Platinum
Standard configuration
Sound power level
L
WAd
(ISO 9296)
4.2 B (standby)
5.0 B (operation)
Sound pressure level at adjacent workstation
L
pAm
(ISO 9296)
24 db(A) (standby)
32 db(A) (operation)
Rated voltage range 100 V - 240 V
Frequency 50 Hz / 60 Hz
Max. rated current 5.0 A - 2.0 A
Active power 450 W
Main power fuse 16 A
Protection class I
Rated voltage range 100 V - 240 V
Frequency 50 Hz / 60 Hz
Max. rated current 9.0 A - 3.5 A
Active power 748 W
Main power fuse 16 A
Protection class I
