Application Unit AU47 Application Unit
18 U41861-J-Z126-1-76
1 CSS indicator (yellow)
– Lights up yellow when a prefailure event was detected which requires Customer
Support to become active (by way of precaution).
– Flashes yellow when an error was detected which requires Customer Support to
become active.
– Does not light up w
hen the Application Unit is OK.
If the event is still acute after the Application Unit has been switched on/off, the
indicator is activated after the restart.
The indicator also lights up in standby mode.
If the indicator flashes yellow, call Customer Support.
2 Global error indicator (yellow)
– Lights up yellow when a prefailure event was detected which requires Customer
Support to become active (by way of precaution).
– Flashes yellow when an error was detected which requires Customer Support to
become active.
– Does not light up when no critical event has occurred.
If the event is still acute after a power failure, the indicator is activated after the restart.
The indicator also lights up in standby mode.
If the indicator flashes yellow, call Customer Support.
3 ID indicator (blue)
Lights up blue when the
Application Unit has been selected by pressing the ID button.
Press the button again to deactivate it.
The ID indicator can also be activated via the ServerView Operations Manager and the
iRMC Web interface, and the status can be reported to the ServerView Operations
Manager and the iRMC.
4 ID button
