169
CHAPTER2 Dependence Functions
● In the case of [Debugger -> Flash]
An image in the case where the flash memory synchronization [Debugger -> Flash] has been performed is
shown below.
Figure 2.4-5 Variations in the values of the internal debugger and flash memory in the case of the flash
memory synchronization [Debugger -> Flash]
Note:
The FLASH loader cannot be used by the emulator debugger (MB2100-01). Therefore, the [FLASH
memory] menu cannot be used.
FF FF FF FF
12 34 56 78
FF
FF
FF
FF
FF
FF
FF
FF
12
34
56
78
Occurrence of flash memory synchronization [Debugger -> Flash]
Debugger Flash memory
Memory writing,
loading, etc. by the user
Execution and reset, etc.
