C120-E360-06EN 2-11
2.5 RCI Setup for Replacement of an RCI I/O Unit
2.5.4 Making an RCI replacement setting
The added RCI I/O unit must be connected to the RCI network.
The RCI address of the added RCI I/O unit is synchronized with that of an existing
RCI host so that the unit can use RCI functions.
An RCI expansion setting can be made only once from an arbitrary RCI host.
Note: Before beginning this RCI setup work, confirm that AC cables are connected
to all RCI units.
Note: To make an RCI expansion setting for an RCI unit equipped with a main line
switch, set the main line switch to the ON position.
• To make an RCI replacement setting:
1 Execute the setrci (8) command, and make an RCI replacement setting.
In <address>, specify the RCI address (eight-digit hexadecimal number) obtained by
RCI address confirmation.
• To confirm an RCI replacement setting:
1 Execute the setrci (8) command to display the RCI status.
On the list, confirm that "ACT" is displayed in the "I/F" column of the RCI I/O unit at
the RCI address specified for the RCI replacement setting.
<Example> Replacing the RCI I/O unit at the RCI address 003002ff
XSCF> setrci -c replaceconfig <003002ff>
....................................................
The command completed successfully.
XSCF> setrci -c stat
HOST
address 000102ff
Active
LIST
address pwr alm I/F sys-phase ctgry dev-cls sub-cls tm-out
000101ff OFF - ACT - host 0001 0b -
003001ff OFF - ACT - disk 0400 04 -
003002ff OFF - ACT - disk 0400 04 -
003003ff OFF - ACT - disk 0400 04 -
The command completed successfully.
