Fujitsu SPARC Enterprise M5000 Overview Guide

Chapter 1 System Overview 1-7
1.2.2 SPARC Enterprise M5000 Server
The SPARC Enterprise M5000 server is a ten-rack unit (10 RU) enclosure (17.25
inches, 438 mm), which supports up to four dynamic server domains.
FIGURE 1-4 and
FIGURE 1-5 illustrates the components. See Section 1.3, “Components” on page 1-9 for
a brief description of each component.
FIGURE 1-4 SPARC Enterprise M5000 Server (Internal Front View)
Location
Number Component
Maximum Number
per Server
1 Memory boards (MEMB) 8
2 CPU modules each containing two processor chips
(CPUM)
4
3 172-mm fans (FAN_A) 4
4 CD-RW/DVD-RW drive unit (DVDU) 1
5 Power supply units (PSU) 4
6 Tape drive unit (TAPEU), optional 1
7 Hard disk drives (HDD), Serial-attached SCSI (SAS) 4
1
1
1
1
1
1
1
1
2
2
2
2
5
3
3
5
5
3
4
7
7
7
7
6
5
3
