Fujitsu SPARC Enterprise M5000 Overview Guide

Chapter 1 System Overview 1-13
FIGURE 1-8 CPU Modules in the SPARC Enterprise M5000 Server
1.3.3 Memory Board
Each memory board provides a memory access controller (MAC) and eight DIMM
slots (
FIGURE 1-9 and FIGURE 1-10). To remove or install memory boards, you must
power the server off.
TABLE 1-5 lists the memory board features.
To install DIMMs, you must remove the memory board and open the case of the
memory board. The servers use Double Data Rate II (DDR-II) type memory with the
following features:
■ Error Checking and Correction (ECC) error protection
■ Recovery from memory chip failures
FIGURE 1-9 and FIGURE 1-10 illustrate the location of the memory boards in both
midrange servers.
TABLE 1-5 Memory Board Features
Location Top of server
Cold FRU replacement capability Yes
