1-12 SPARC Enterprise M4000/M5000 Servers Overview Guide • August 2009
The CPU modules can be accessed from the top of the midrange server. FIGURE 1-7
and FIGURE 1-8 illustrate the number of CPU modules per midrange server and their
location.
TABLE 1-4 lists features of the CPU modules. For additional information on
the CPU module, refer to the SPARC Enterprise M4000/M5000 Servers Service Manual.
FIGURE 1-7 CPU Modules in the SPARC Enterprise M4000 Server
TABLE 1-4 CPU Module Features
CPU module location Top of server
Cold FRU replacement capability Yes
