Fujitsu SPARC Enterprise M5000 - Using the Diagnostic Commands

Chapter 1 System Overview 1-21
FIGURE 1-15 Operator Panel
Location Number Function
1 Operator panel (FRU)
2 POWER LED
3 XSCF STANDBY LED
4 CHECK LED
5 Power switch
6 Mode switch (keyswitch)
7 Antistatic ground socket
2
5
6
3
4
1
7
