Ports and cont rols
Ports and controls
This chapter presents the individual hardware components of your device. It gives an
overview of the indicators and connections of the device. Please familiarize y ourse lf
with these items before you sta rt to w ork with the device.
Front
4
5
6
3
2
7
1
1
9
10
8
8
1 = Speaker
2 = Power-on in
dicator
3 = Touch screen
4 = Front webc
am
5 = Webcam status LED (blue)
6 = Ambient l
ight sensor
7 = Battery chargin g indicator
8 = Mechanical
attachment for the keyboard
cover or cr
adle
9 = Docking port
10 = Center ali
gnment point
10 Fujitsu
