Fujitsu STYLISTIC Q738

To Next Page

To Previous Page

Accessories for your Tablet PC (opti

onal)

Protective TPU cover with hand strap (optional)

Prepare installation

► Remove the soft pad from the hand strap be lt (2).

► Loosen and remove the hand strap belt (1).

► Separate the rigid c over (3) from the soft cover (4).

Fujitsu 57
