0 = Suction 1
1 = Suction 2
2 = Suction 3
19.PARAMETER TABLE
1.7.6.x.6 Alarm hysteresis:
Hysteresis of temperature alarms.
1.7.6.x.7 Linked pressure switch:
Allows you to link the thermostat to a suction pressure switch.
1.7.6.x.8 Temperature sensor:
Specifies the temperature sensor.
1.7.6.x.9 Main output address:
Output address linked to the individual thermostat.
1.7.6.x.10 NO-NC contact type:
Defines the actuation state of the main output
1.7.6.x.11 Minimum time output on:
Minimum time output on/off.
1.7.6.x.12 Defrost output address:
Output address linked to the individual thermostat to defrost.
1.7.6.x.13 Contact type NO-NC (defrost):
Defines the operating state of the defrost output.
1.7.6.x.14 Interval between defrosts:
Time interval between the defrosts.
1.7.6.x.15 Defrost length:
Time interval during which the thermostat remains in defrost.
1.7.6.x.16 to 1.7.6.x.21 Defrost time:
It allows configuring a specific time to defrost. In this case, the defrost interval parameter will not be considered.
1.7.7 Rotation outputs:
1.7.7.x.1 Rotation outputs time:
Operation time of an output before entering rotation.
1.7.7.x.2 Transition time:
Time that the two outputs remain on during rotation.
1.7.7.x.3 Digital output 1 address:
Digital output address for rotation
1.7.7.x.4 Digital output 2 address:
Digital output address for rotation.
0 = NO: When the output is actuated, the contact is closed.
0 = NO: When the output is actuated, the contact is closed.
1 = NC: When the output is actuated, the contact is open.
1 = NC: When the output is actuated, the conctact is open.
Feature
Minimum
Maximum Unit
Standard
Description
1.7.7.x.1
1.7.7.x.2
1.7.7.x.3
1.7.7.x.4
9999
9999
0 0
0 5
0 720
sec.
min.
-
-
0 0
-
-
Transition time
Digital output 2 address
Rotation outputs time
Digital output 1 address
67
