Compressor reference
Indicates the set to which the output belongs
Suction line
Protection output status
Indicates the output index
Compressor temperature
Indicates the output index
On: Output on
Off: Output off
AL: Alarm output
12.SUMMARY SCREEN
12.8. Compressor protection thermostats:
Thermostat information is accessed from the Control Menu.
To toggle between the available compressors just navigate using the keys and .
12.9. Rotation outputs:
It allows viewing the status of the outputs of the sets of rotation outputs.
4
1
1
3
3
2
2
Therm. compressors
Rotation output
Suc. 1 Temp:
Comp.1 Out
Suc. 1 Temp:
Comp.2 Out
Suc. 1 Temp:
Comp.3 Out:
50.0 °C
Off
50.0 °C
Off
50.0 °C
Off
CJ.1-Output 1: On
CJ.1-Output 2: Off
CJ.2-Output 1: On
CJ.2-Output 2: Off
CJ.3-Output 1: On
CJ.3-Output 2: AL
18
