7
[5,34"]135,7 mm
[2,76"]
70 mm
USB
7.1 DIN rail.Fixing by
To fix the interface on the DIN rail, position the interface as shown and fit the top part.
7.INSTALLING THE RCK-862 plus
To remove the controller from the DIN rail, use a
wrench compatible with the size of the lock to make
a lever.
3,21"
1,80"
110 mm [4,33'’]
[2,43"]
61,7 mm
8. DIMENSIONS
For a better fixation of the RCK-862 plus observe the product dimensions.
