19.PARAMETER TABLE
1.7.8 Control status output:
1.7.8.1 Digital output address:
Digital output that indicates that the controller is operating.
1.8 Maintenance time:
Time setting for maintenance of compressors and fans.
1.8.x Suction / Discharge:
The letter x represents suctions (x between 1 and 3) and discharges (x between 4 and 6).
1.8.x.1 Time for compressor / fan maintenance 1 to 6:
Time for the alarm of hours worked of the compressor or fan.
1.9 Sensors:
Settings related to sensors.
1.9.x Sensors S1-S6:
The letter x represents the sensor inputs S1 to S6.
1.9.x.1 Pressure at 4mA:
Sensor pressure value at 4mA (low full scale).
1.9.x.2 Pressure at 20mA:
Sensor pressure value at 20mA (high full scale).
1.9.x.3 Pressure offset:
It allows to offset deviations in the pressure reading.
1.9.x.4 Temperature offset:
It allows to offset deviations in the temperature reading.
1.10 Analog outputs:
Configuration of limit values for analog outputs.
1.10.x Analog outputs A1-A2:
The letter x represents the analog outputs A1 and A2.
Feature
Minimum
Maximum Unit
Standard
Description
1.7.8.1
-
0 0
-
Digital output address
Feature
Minimum
Maximum Unit
Standard
Description
1.8.x.1
1.8.x.2
1.8.x.3
1.8.x.5
1.8.x.4
1.8.x.6
9999
9999
0 [off]
0 [off]
0 [off]
0 [off]
0 [off] 0 [off]
0 [off] 0 [off]
h
h
h
h
h
h
0 [off]
0 [off]
0 [off]
0 [off]
9999
9999
9999
9999
Maintenance time for compressor / fan 02
Maintenance time for compressor / fan 04
Maintenance time for compressor / fan 06
Maintenance time for compressor / fan 01
Maintenance time for compressor / fan 03
Maintenance time for compressor / fan 05
Feature
Minimum
Maximum Unit
Standard
Description
1.9.x.1
1.9.x.2
1.9.x.3
1.9.x.4
850,0 (58,6)
850,0 (58,6)
-50,0 (-90,0) 0 (0)
0 500,0 (34,5)
0 0
Psi (Bar)
Psi (Bar)
Psi (Bar)
°C (°F)
-50,0 (-3,4) 0
50,0 (-3,4)
50,0 (90,0)
Pressure at 20mA
Temperature offset
Pressure at 4mA
Pressure offset
Feature
Minimum
Maximum Unit
Standard
Description
1.10.x.1
1.10.x.2
1.10.x.2
1.10.x.3
100
100
2
0
0
0
0
0 0
%
%
-
%
0 100
100
Analog output starting value
Minimum analog output value
Analog output actuation range
Maximum analog output value
68
