STANDARD TRIM ITEMS
Additions and Optional items should be requested when ordering the boiler
BOILER TRIM 6E 8E 10E 15E 20E 30E 40E 50E 60E
Steam Safety
Valve (Discharge side) (DN) 32 32 32 32 32 32 32 32 32
Steam Outlet
Valve (DN) 20 20 25 32 32 40 50 50 50
Feed Water Stop
Valves (DN) 25 25 25 25 25 25 25 25 25
Feed Water
Check Valve (DN) 25 25 25 25 25 25 25 25 25
Boiler Blowdown
Valves (DN) 20 20 20 20 25 25 25 25 25
Water Column
Blowdown Valves (DN) 20 20 20 20 20 20 20 20 20
Sight Glass
Blowdown Valve (DN) 666666666
WARNING
It is the responsibility of the installer to ensure all parts supplied
with the boiler are fitted to the boiler in a correct and safe manor.
Standard Boiler Trim. Quantity
Main Steam Valve 1
Steam Safety Valve 1
Steam Pressure Gauge Assembly 1
Boiler Blowdown Valve 1
Water Level Gauge Set 2
Feedwater Check Valve 1
Feedwater Stop Valve 1
Flue Spigot 1
Audible Alarm 1 or 2*
Flue Brush 1
Tee Handle Wrench 1
Items marked * vary according to boiler specification.
