FT-C Vertical Electric Thermal Fluid Heater Manual 12 2013 ISSUE 1
The Fulton FT-C is a vertical thermal uid heater with a range of 11 models. The Fulton FT-C Thermal
Fluid Heater offers a compact fuel red 4-pass heater design capable of operating temperatures up
to 345°C
The heater is of a vertical, helical coil self venting design, and the pressure vessel coil construction
shall be carbon steel ASME SA106B, Schedule 40 or equal. The design pressure is 13.8 barg
standard at 370°C. The heater will be per ASME Code Section I stamped at 10.34 barg maximum
working pressure, trimmed at 6.9 barg unless otherwise specied. Test pressure will be per ASME
Code Section I. Minimal refractory lining shall be supplied in heater combustion chamber to avoid
thermal inertia and overheating of the thermal uid should a pump or power failure occur.
The shell, coil and burner are surrounded by the pre-heater jacket. This jacket is a welded steel
construction with an integral oor plate and bolted top cover to facilitate coil removal, access panels
for air chamber inspection and has an aluminium inner air bafe. This pre-heater obviates the
requirement for insulation of the heater and simultaneously boosts thermal efciency by preheating
incoming combustion air.
for a full specication please refer to .
234
351
468
703
937
1171
1757
2342
2928
3514
4100
