steam and water. The brass valve stem must be opened
fully to enable this feature If the valve is in any other
position, the ball will not seat.
PROOF OF CLOSURE  IF APPLICABLE TO YOUR
MODEL
1. Disconnect power to the boiler.
2. While the boiler is o, remove the common wire
to the proof of closure (POC) switch on the oil/gas
valve.
3. Restore power to the boiler. The boiler should
immediately lock out on alarm due to the POC
being disconnected.
4. Disconnect power and reconnect the POC wire.
5. Restore power to the boiler and reset any ame
programmer faults.
6. Cycle the burner and observe for proper
operation.
Cycle Testing
The boiler should be cycle-tested and automatically
allowed to go through its normal starting sequence
several times to verify that all components are
functioning accurately.
This will also verify that combustion is set properly so
that boiler light-o has a smooth transition from ignition
to main ame.
It is recommended that a minimum of 10 cycles should
be met without any ame failures, with combustion
readings comparable to the factory test re sheet and no
interlocks causing the boiler to shutdown.
Daily Start-Up
To initiate daily start-up:
1. Turn Switch to On or Local (depending on
model). The blower/fan will start up and ramp to
high re speed/rpm. The blower/fan will purge for
30 seconds, then ramp down to light o position
(near low re). When stable, ignition sequence
begins.
2. As spark is generated inside the combustion
chamber, the pilot gas valve opens. There should
be an audible click of the pilot solenoid valve.
3. Once pilot ame is established, the main gas valve
will open. There should be an audible click from
the main gas valve solenoid valve. There may be a
slight whooshing sound as the main burner ame
lights.
Daily Shutdown
To initiate daily shutdown:
1. Turn switch to O. If burner is currently on, the
unit will start ramping down to low re before
turning o.
2. Gas valve will shut. The blower/fan may increase
speed briey as the ow of gas is cut o. The
blower/fan will ramp to high-re speed/rpm, and
continue to run there for a 15-second post purge.
