FULTON VSRT 50 - Routine Maintenance Schedules

4  MAINTENANCE & TROUBLESHOOTING
© Fulton 2018
4-2
VSRT_IOM_2018-1213
! WARNING
Prior to the commencement of any work requiring the
removal of cover plates and the opening of the control
panel box, the electrical supply to the boiler must be
disconnected.WARNING:
Proper lockout / tagout procedures must be employed
when servicing this unit. WARNING
Hazard analysis should be performed by end user
to insure safety of their employees and/or service
technicians.WARNING
Qualied and knowledgeable personnel should
perform all weekly, monthly and annual maintenance
checks.WARNING:
Label all wires prior to disconnecting when servicing
controls. Wiring errors can cause improper and
dangerous operation.
! CAUTION
Verify proper operation after servicing.CAUTION
To ensure the continued safety and eciency of
the boiler, you must adhere to the schedule of
maintenance outlined in this section.
Installation and service must be performed by a
qualied and knowledgeable individual, such as
a Fulton Steam Solutions representative, qualied
installer, service agency or gas supplier. Any potential
warranty issues that arise after an unqualied
individual has manipulated boiler parameters will not
be considered.
Procedure for Cleaning Water Probes
To clean probe on top of boiler shell and probes in water
column:
1. Make sure there is no pressure in the boiler
during the removal of the probes.
2. Remove one probe (using a 7/8” socket), clean
with very ne emory cloth and replace it before
removing another to assure no probe mix-ups
that would change the control functions. For
replacement purposes, installed probe lengths
are indicated in Figure 18. For a universally
adaptable plug and probe which can be cut to
length in the eld to t all boilers, order Part No.
2-20-017.
Flame Scanner Adjustments for
Fulton Gas Fired Steam Boilers
Flame detector adjustments are made with the
detectors installed and the burner running. It is essential
to obtain optimum ame signal detection for safe and
continual operation of the control relay
If a detector is inoperable, it may prove the detector is
working and only an adjustment to the ame is needed
to improve the signal.
If the detector is found to be defective, replace.
Adjustments to establish a good signal may include the
following:
• Air damper adjustments in the combustion settings.
• Adjusting gas pressure through the gas regulator.
