FULTON VSRT 50 - Page 57

OPERATION  3
Questions? Call (315) 298-5121, or visit us online at www.fulton.com
3-13
VSRT_IOM_2018-1213
Par. No.
Parameter Min Value Max Value Fulton Setting Customer
163
Operating hours when unit is live 0 h 99999999 h
164
Number of start ups resettable 0 99999999
166
Total number of start ups 0 9999999
167
Fuel volume resettable 0 99999999
200
Burner Control
201
Burner operating mode (fuel train, modulating /
multistage, actuators, etc.)
-- = undened (delete curves)
1 = G mod
2 = Gp1 mod
3 = Gp2 mod
4 = Lo mod
5 = Lo 2-stage
6 = Lo 3-stage
7 = G mod pneu
8 = Gp1 mod pneu
9 = Gp2 mod pneu
10 = LoGp mod
11 = LoGp 2-stage
12 = Lo mod 2 fuel valves
13 = LoGp mod 2 fuel valves
14 = G mod pneu without actuator
15 = Gp1 mod pneu without actuator
16 = Gp2 mod pneu without actuator
17 = Lo 2-stug without actuator
18 = Lo 3-stug without actuator
19 = G mod only gas actuator
20 = Gp1 mod only gas actuator
21 = Gp2 mod only gas actuator
22 = Lo mod only oil actuator
1 22 3
208
Program stop
0 = deactivated
1 = PrePurgP (Ph24)
2 = IgnitPos (Ph36)
3 = interval 1 (Ph44)
4 = interval 2 (ph52)
0 4 0
210
Alarm in the event of start prevention
0 = deactivated
1 = activated
0
1 0
211
Fan ramp up time
2 s
60 s 5 s
212
Max time down to low re
0.2 s
10 min 30 s 10 s
213
Min time home run 2 s 60 s
2 s
214
Max time start release
0.2 s
10 min 20 s
215
Repetition limit safety loop 1 16 1
217
Max time to detector signal
5 s
10 min 30 s
221
Gas: Active detector ame evaluation
0 = QRB / QRC
1 = ION / QRA
0 1 1
222
Gas: Pre-purging
0 = deactivated
1 = activated
0 1 1
*Data is for reference purposes only. Fulton Companies is not responsible for this product, including (but not limited to) its accuracy, reliability, and safety.
No Fulton document should substitute for full review of documentation available from the product manufacturer.
+Out of Test Fire
Note: Customer settings should be recorded in the Customer column for reference.
Table 7 - Steam Program for Siemens LMV3*
