FULTON VSRT 50 - Page 78

4  MAINTENANCE & TROUBLESHOOTING
© Fulton 2018
4-18
VSRT_IOM_2018-1213
FRONT VIEW
TOP VIEW
BILL OF MATERIAL
U.O.M.QTYDESCRIPTIONREVPART NUMBERITEM
EA.2LOUVER 3IN REG 6 TABS
-
2-21-0000321
EA.1
30" X 24" X 8.62" NEMA 1 PANEL BOX
2-21-0001002
EA.1
VSRT PANEL BOX - 5 HOLE OVERLAY
-
2-23-2900003
EA.1WALCHEM CONDUCTIVITY CONTROL WITH ANOLOG OUTPUT
(WCNP110-A-N)
2-40-0003714
EA.1
AZL DISPLAY MODULE FOR LMV 3 2-40-000473
5
EA.1YOKOGAWA UT32A PROCESS CONTROLLER 2-40-0008636
EA.13/8" T&B STRAIGHT CONNECTOR 2-45-0000337
EA.6
3/8" DUPLEX CONNECTOR
2-45-0000398
EA.
61/2" STRAIN RELIEF CORD CONNECTOR - T&B
-
2-45-0001659
EA.1ILLUM 2 POS GREEN SWITCH 1 NO / 1 NC CONTACT
-
2-45-00030710
EA.2RED 120V PILOT LIGHT 2-45-00041111
EA.1
120V RED ILLUMINATED PUSH BUTTON W/ SINGLE POLE N/C CONTACT 2-45-00054512
EA.1120V RED ILLUMINATED PUSH BUTTON W/ SINGLE POLE N/O CONTACT 2-45-00054613
EA.1VSRT-30 BACK PLATE FOR 24" X 30" MODULATED PANEL BOX
-
5-21-03031214
4
6
5
11
9 8
7
9
9
1
1
2
10
12
13
