FUNAI HDR-A2835D - Page 76

20061213 1-20-3 E434GEL
C481 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C482 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C483 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C484 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C485 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C486 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C487 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V H7
CE1CMAVSM470
C488 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C502 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C506 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C507 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C509 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C510 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C511 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C514 CHIP CERAMIC CAP. B K 330pF/50V CHD1JK30B331
C515 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C516 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C517 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C518 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C519 CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C521 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C522 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C524 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C527 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C531 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C533 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C534 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
6.3V H7
CE0KMAVSM470
Ref. No. Mark Description Part No.
C535 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C538 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C539 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C540 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C541 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C542 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C545 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C546 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C547 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C548 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C549 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C550 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/6.3V H7
CE0KMAVSM101
C553 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C554 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/6.3V H7
CE0KMAVSM101
C555 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C558 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C560 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C611 ELECTROLYTIC CAP. 22µF/50V M H7 or CE1JMASSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
50V H7
CE1JMASSM220
C612 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C614 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C616 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1501 PCB JUMPER D0.6-P5.0 JW5.0T
C1502 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C1506 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1507 ELECTROLYTIC CAP. 220µF/25V M or CE1EMASDL221
ELECTROLYTIC CAP. 220µF/25V M CE1EMASTM221
C1508 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
C1509 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C1510 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1511 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1512 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
Ref. No. Mark Description Part No.
