FUNAI HDR-A2835D - Page 77

20061213 1-20-4 E434GEL
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1514 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1515 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1517 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1519 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C1520 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1521 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1522 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1525 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1526 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1527 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1528 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1530 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1532 CHIP CERAMIC CAP. CH J 20pF/50V CHD1JJ3CH200
C1533 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C1536 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1537 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASTM470
C1539 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1540 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C1541 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1542 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1543 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1544 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1546 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1547 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1548 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
If C1549 is 0.015µF, then IC1502 is R3112N191A-TR-FA, R3112N191A-TR-FB or
BU4219G-TR.
C1549 CHIP CERAMIC CAP.(1608) B K 0.015µF/
50V
CHD1JK30B153
IC1502 VOLTAGE DETECT R3112N191A-TR-FA
or
QSZBA0TRC021
VOLTAGE DETECT R3112N191A-TR-FB
or
QSZBA0TRC022
RESET IC BU4219G-TR QSZBA0TRM090
If C1549 is 0.1µF, then IC1502 is PST3619NR.
Ref. No. Mark Description Part No.
C1549 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
IC1502 SYSTEM RESET IC PST3619NR QSZBA0TMM151
C1550 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
25V M
CE1EMASTM470
C1551 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASTM470
C1552 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1553 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C1554 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1555 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C1557 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1558 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1559 CHIP CERAMIC CAP.(1608) CH J 270pF/
50V
CHD1JJ3CH271
C1560 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1561 CHIP CERAMIC CAP.(1608) CH J 270pF/
50V
CHD1JJ3CH271
C1562 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1563 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1564 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1565 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1566 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1567 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1568 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1569 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1570 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1571 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1572 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1573 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1574 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V M
CE1EMASTM4R7
C1575 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1576 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1577 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1578 ELECTROLYTIC CAP. 0.47µF/50V M or CE1JMASDLR47
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C1579 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1581 ELECTROLYTIC CAP. 47µF/10V M or CE1AMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
10V M
CE1AMASTM470
Ref. No. Mark Description Part No.
