20071107 13-5 A73F0EL
FUNCTION CBA
IR SENSOR CBA
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R820 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002
R851 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R853 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R854 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R855 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R856 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R857 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R858 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R859 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R860 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R863 CHIP RES. 1/10W J 3.6k Ω or RRXAJR5Z0362
RES CHIP 1608 1/10W J 3.6k Ω RRXA362YF002
R864 CHIP RES. 1/10W J 3.6k Ω or RRXAJR5Z0362
RES CHIP 1608 1/10W J 3.6k Ω RRXA362YF002
R867 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R868 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R869 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R870 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R873 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R874 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
B10 HEAT SINK PKH ASSEMBLY L3201UB 1EM420648
B11 HEAT SINK PKP ASSEMBLY L4200EA 1EM420855
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC631 PCB JUMPER D0.6-P5.0 JW5.0T
BC632 PCB JUMPER D0.6-P5.0 JW5.0T
BC633 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC634 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC635 PCB JUMPER D0.6-P5.0 JW5.0T
BC801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC802 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC803 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC804 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
CLN51 WIRE ASSEMBLY 12PIN/230MM/UL2468 WX1A73F0-004
J733 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
JS612 PCB JUMPER D0.6-P7.5 JW7.5T
JS632 PCB JUMPER D0.6-P17.0 JW17.0T
JS802 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
L6 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T601! TRANS POWER 7726 LTT4PE0KT002
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITORS
C108 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C109 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C110 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
Ref. No. Description Part No.
CONNECTORS
CN102 CONNECTOR PRINT OSU S6B-PH-K-
S(LF)(SN) or
J3PHC06JG030
CONNECTOR PRINT OSU C R 440055-6 J344C06AP006
RESISTORS
R115 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R116 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R117 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R118 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R119 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R120 CHIP RES. 1/10W J 6.8k Ω or RRXAJR5Z0682
RES CHIP 1608 1/10W J 6.8k Ω RRXA682YF002
R121 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R122 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002
R123 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R124 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R125 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R126 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R131 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
SWITCHES
SW108 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW109 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW110 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW111 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW112 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW113 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW114 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
MISCELLANEOUS
BC102 PCB JUMPER D0.6-P5.0 JW5.0T
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C101 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C102 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C106 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C107 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
Ref. No. Description Part No.
To Next Page
