FUNAI LC5-D32BB - Page 64

20071107 13-6 A73F0EL
JACK CBA
CONNECTORS
CN801 PH CONNECTOR SIDE 2P S2B-PH-K-
S(LF)(SN)
J3PHC02JG030
CN802 PH CONNECTOR SIDE 2P S2B-PH-K-
S(LF)(SN)
J3PHC02JG030
DIODES
D101 LED L-53HT or NP4Z000L53HT
LED 333HT/E-L or NPHL00333HTE
LED 333HT/E-K NPHK00333HTE
D102 LED 333GT/E NPHZ00333GTE
RESISTORS
R101 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R102 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R103 CHIP RES. 1/10W J 470 Ω or RRXAJR5Z0471
RES CHIP 1608 1/10W J 470 Ω RRXA471YF002
R105 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
MISCELLANEOUS
BC101 PCB JUMPER D0.6-P5.0 JW5.0T
RCV891 PHOTO LINK MODULE KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JACK CBA
Consists of the following:
1ESA14664
CAPACITORS
C7001 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C7002 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
C7003 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7004 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 47µF/10V M or CA1A470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/10V M CE1AMASTM470
C7005 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7006 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7007 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7008 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7009 CHIP CERAMIC CAP.(1608) CH J 270pF/50V CHD1JJ3CH271
C7010 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7011 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C7012 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7013 CHIP CERAMIC CAP.(1608) CH J 270pF/50V CHD1JJ3CH271
C7014 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7015 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C7016 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 47µF/10V M or CA1A470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/10V M CE1AMASTM470
C7017 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
C7018 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7019 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7020 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7021 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7022 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7023 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7024 CHIP CERAMIC CAP.(1608) CH J 270pF/50V CHD1JJ3CH271
C7025 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7026 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C7027 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7028 CHIP CERAMIC CAP.(1608) CH J 270pF/50V CHD1JJ3CH271
C7029 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7030 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C7031 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C7101 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C7102 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
Ref. No. Description Part No.
C7104 CHIP CERAMIC CAP. B K 270pF/50V CHD1JK30B271
C7105 CHIP CERAMIC CAP. B K 270pF/50V CHD1JK30B271
C7106 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7107 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7108 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C7201 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C7202 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C7203 CHIP CERAMIC CAP. B K 270pF/50V CHD1JK30B271
C7204 CHIP CERAMIC CAP. B K 270pF/50V CHD1JK30B271
C7205 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7301 CHIP CERAMIC CAP. F Z 0.047µF/50V CHD1JZ30F473
C7302 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7303 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7304 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7305 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7306 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7307 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7308 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7309 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7310 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7401 CHIP CERAMIC CAP. B K 270pF/50V CHD1JK30B271
C7402 CHIP CERAMIC CAP. B K 270pF/50V CHD1JK30B271
C7403 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C7404 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C7501 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C7502 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C7505 ELECTROLYTIC CAP 47µF/10V H7 or CE1AMAVSM470
ELECTROLYTIC CAP. 47µF/10V M H7 CE1AMAVSL470
C7506 ELECTROLYTIC CAP. 220µF/6.3V M H7 or CE0KMAVSL221
ALUMINUM ELECTROLYTIC CAP 220µF/6.3V
H7
CE0KMAVSM221
C7508 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7509 ALUMINUM ELECTROLYTIC CAP 100µF/10V
H7 or
CE1AMAVSM101
ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMAVSL101
C7510 ALUMINUM ELECTROLYTIC CAP 100µF/10V
H7 or
CE1AMAVSM101
ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMAVSL101
C7511 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C7512 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C7513 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C7514 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7701 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C7702 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C7703 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7704 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7705 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7706 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7707 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7708 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7709 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7710 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7711 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7712 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7713 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7714 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C7715 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C7716 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7717 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7718 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7719 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7720 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7721 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7722 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7723 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
C7724 CHIP CERAMIC CAP. F Z 0.47µF/10V CHD1AZ30F474
