Funkwerk GSM-R User Manual

Trackside Worker GSM-R User Guide
10
th
March 2015 Page 12
5.4 Pictograms in the Display Field
Incoming point-to-point call Setup of a conference call
Setup of a point-to-point call Existing conference call
Existing point-to-point call Conference call is busy
Point-to-point call is placed on hold Conference call failed
Waiting point-to-point call Setup Group call
Point-to-point call is busy Setup Broadcast call
Line is busy Incoming Group- / Broadcast call
No point-to-point call is possible, there is Waiting Group- / Broadcast call
no connection or the connection will
be lost.
Point-to-point call failed Existing Group- / Broadcast call
Call interrupt Group- / Broadcast call failed
Incoming conference call Incoming / outgoing emergency call
Emergency call active / emergency call ended
Table 4 Pictograms in the Display Field
