EQUIPMENT LISTS
Standard supply
Optional equipment
Name Type Code No. Qty Remarks
Display Unit DS-8500 – 1
Distributor Unit DS-8510-1 – 1 For 100 VDC, no LIF board
DS-8510-2 – 1 For 200 VDC, no LIF board
DS-8510-1-LIF – 1 For 100 VDC, w/LIF board
DS-8510-2-LIF – 1 For 200 VDC, w/LIF board
Transceiver Unit DS-8520 – 1
Transducer DS-8530 – 1 10/20/30/40 m cable
Installation Materials CP05-13701 001-426-520 1 For DS-8500
CP65-01501 001-569-940 1 For DS-8510
CP65-01401 001-569-870 1 For DS-8520
Spare Parts SP65-01101 001-569-930 1 For DS-8510
SP65-01001 001-569-860 1 For DS-8520
Name Type Code No.
Remarks
(*: degree of protection,
**: See section 1.5.3)
Display Unit DS-8500 – For sub display
Remote Display RD-50 –
RD-20 –
Analog Indicator FL-200S-1 000-015-997-10 Flush
mount
Scale range: -10 to 30 kn IP5X*
FL-200S-1W 000-020-297-10 Scale range: -10 to 30,
-2 to 6 kn (double
scale**)
FL-200S-2 000-015-998-10 Scale range: -10 to 40 kn
FL-200S-3 000-020-296-10 Scale range: -10 to 20 kn
SL-200-1W 000-034-151 Bulk-
head
Scale range: -10 to 30,
-2 to 6 kn (double
scale**)
IP56*
SL-200-5W 000-034-152 Scale range: 30 to -10,
6 to -2 kn (double
scale**)
SL-200-1 000-016-000-10 Scale range: -10 to 30 kn
SL-200-2 000-016-164-10 Scale range: -10 to 40 kn
SL-200-3 000-029-425 Scale range: -10 to 20 kn
SL-200-4 000-037-721 Scale range: -10 to 30, -
2 to 6 KTS (double
scale**)
SL-200-5 000-037-722 Scale range: 30 to -10 kn
Range Selector MF-22R-1 000-069-391 Flush mount
MF-22R-2 000-069-392 Bulkhead
