AP4. Program ROM
4.1 Communication Equipment ROM List
Model PCB type ROM Version No. ROM type Note
AA-
50/50R
05P0514
(CONTROL)
U4 05-501-45-1xx M27C256B-10F1 CONTROL
05-501-48-140
05P0407A
(CONTROL)
05-501-48-141
M27C4001-10F1
For Old type
LCD(yellow)
Full parts
Note)
DMC-5
05P0407E
(CONTROL)
U8
05-501-48-143
and after
M27C4001-10F1
For new LCD
type (green)
Reject parts
05P0407
-none
(CONTROL)
05-501-39-141 M27C4001-10F1
For Old type
LCD(yellow)
Full parts
05P0407D
(CONTROL)
U8
05-501-39-142
and after
M27C4001-10F1
For new LCD
type (green)
Reject parts
U2 05-501-40-1xx
Note)
DSC-
5/5A/5R
5AR/5V
05P0370A
(MODEM)
U3 05-501-40-2xx
WS57C49C-45D MODEM
05-501-68-102
05P0407C
(CONTROL)
05-501-68-103
M27C4001-10F1
For Old type
LCD(yellow)
Full parts
05P0407G
(CONTROL)
U8
05-501-68-105
and after
M27C4001-10F1
For new LCD
type (green)
Reject parts
U2 05-501-40-1xx
Note)
DSC-6/6A
05P0370A
(MODEM)
U3 05-501-40-2xx
WS57C49C-45D MODEM
05-501-67-102
05P0407B
05-501-67-103
M27C4001-10F1
For Old type
LCD(yellow)
Full parts
05P0407F
U8
05-501-67-104
and after
M27C4001-10F1
For new LCD
type (green)
Reject parts
U2 05-501-40-1xx
Note)
DSC-
8V/8VP
05P0370A
(MODEM)
U3 05-501-40-2xx
WS57C49C-45D MODEM
U4 05-502-01-1xx
FD
U4:MBM29F800TA-70PFTN
(Flash ROM)
MAIN
(Update from FD)
DSC-60
(FD:both for
DSC
and MODEM)
05P0702
(CONTRL)
U11 05-502-02-1xx
FD
U11:MBM29F400BC-
90PFTNFK (Flash ROM)
MODEM
(Update from FD)
Note) Refer to section “4.2 Compatibility of CONTROL board,
and LCD module changed”.
