2. SHIP INFORMATION INPUT
2-6
For the PC, click [Apply] or [Apply All] to confirm the settings.
Note: If you entered the MMSI, the following message appears when clicking [Apply]
or [Apply All].
Click [Yes] to save the settings, [No] to cancel the settings.
For the external display, the same message appears when entering the MMSI. Select
[Yes] to save the settings, [No] to cancel the settings. When selecting [Yes], the same
message appears again. Select [Yes] again.
[Silent Mode] When selecting [Software Switch] in the [Silent
Mode Controller] menu, the [Silent Mode] menu
(see right-hand figure) appears on the screen.
Select the FA-70 function from [Normal (TX/RX)]
or [RX Only].
[Normal (TX/RX)]: The FA-70 transmits and re-
ceives.
[RX Only]: The FA-70 receives only.
[Ship Static]
[MMSI] Enter the ship’s MMSI (nine digits). The available MMSI numbers are
displayed at the bottom of the screen.
Note 1: When the ship’s MMSI has already been set, the number is only
displayed.
Note 2: You can enter the MMSI only once. If it becomes necessary to
change the MMSI, contact your dealer.
Note 3: When the MMSI is not set, you can not transmit the data.
[Ship Name] Enter the ship's name, using up to 20 alphanumeric characters.
[Call Sign] Enter the call sign, using seven alphanumeric characters.
[Ship Type] Select the ship type.
[Cargo Type] Select the cargo type. Available options depend on the setting of [Ship
Type].
[Serial Number] Shows the serial number for the equipment.
[Antenna Position] Set the antenna position referring to the following figure.
Menu item Description
A: Distance from bow to GPS
antenna position
(setting range: 0 to 511 m)
B: Distance from stern to GPS
antenna position
(setting range: 0 to 511 m)
C: Distance from port to GPS
antenna position
(setting range: 0 to 63 m)
D: Distance from starboard to
GPS antenna position
(setting range: 0 to 63 m)
XXXXXXXXX
Yes No
