3-1
3. SETTINGS AND STATUS
3.1 IO setup (input/output port)
You can change the input/output settings from the [IO Setup] menu.
[IO Setup] menu for PC
Menu item Description
[Common]
[Port Priority (Heading)]
[1st], [2nd], [3rd]
Set the input port priority for heading data.
[NMEA2000]
[CAN Unique Number] Shows the CAN unique number.
[CAN Address] Shows the CAN address.
[Output Mode] Select the output mode among [OFF], [AIS], [GNSS], or [AIS + GNSS].
[OFF]: Does not output AIS or GNSS data.
[AIS]: Outputs AIS data.
[GNSS]: Outputs GNSS data.
[AIS + GNSS]: Outputs both AIS and GNSS data.
[Format] Select the output PGN format version from [NMEA2000 V2] or
[NMEA2000 V1].
[NMEA0183]
[NMEA1 Output Mode],
[NMEA2 Output Mode]
Select the output mode among [OFF], [AIS], [GNSS], or [AIS + GNSS].
[NMEA1 Speed],
[NMEA2 Speed]
When selecting [OFF] or [GNSS] in the [NMEA1/NMEA2 Output Mode]
menu, select the baudrate for NMEA1/NMEA2 from [AIS: 38400 bps] or
[Sensor: 4800 bps].
[CAN Unique Number], [CAN Address]: Display only.
