3.2
Box Menu
Box Menu Box Menu
Box Menu
3-19
[MARK]
Table 3.2.13 MARK Box Menu
Menu Submenu Description
1 ORIGIN MARK STAB GND/SEA
Set the method for displaying the origin mark.
- GND: The entered mark position is geographically
fixed.
- SEA: The entered mark position is displayed in
correlation with the own ship.
The own ship position and gyro data are required.
The mark number and symbol mark are specified in
“2 MARK KIND” listed below.
2 MARK KIND
ORIGIN MARK (No)
ORIGIN MARK (SYM)
MAP MARK
WP1-50
WP51-100
WP101-150
WP151-198
OWN SHIP SHAPE
Allows the selection of ORIGIN MARK, MAP
MARK, WPT, OWN SHIP SHAPE to be entered.
To select a mark kind, place the cursor on a desired
[MARK] box menu and select it with the wheel.
In the OWN SHIP SHAPE, you can modify the
default ship mark by specifying points (up to 10
points) in the [MARK] box menu.
The ship mark display is toggled between ON and
OFF in [Menu] -> 2 -> 2.
Entered marks can be deleted by selecting MARK
DELETE in [CURSOR] menu, placing the cursor on
the mark, and clicking click the left button.
8 MARK POS COUSPR/OS/L/L
Method of entering the mark position such as WPT
and MAP MARK specified in “2 MARK KIND.”
9 MAP DISPLAY OFF/ON
Turns on and off the mark entered in MAP MARK.
0 MAP MARK COLOR
RED/GRN/BLU/YEL/CYN/
MAG/WHT
Not available on IMO and A type radars. Specifies
the color of MAP MARK and ORIGIN MARK.
[MARK MENU]
1 ORIGIN MARK STAB
GND/SEA
2 MARK KIND
ORIGIN MARK(No.)/
ORIGIN MARK(SYM)/
MAP MARK/
WP 1~50/
WP 51~100/
WP 101~150/
WP 151~198/
OWN SHIP SHAPE
9
MAP DISPLAY
OFF/ON
0
MAP MARK COLOR*
RED/GRN/BLU/YEL/
CYA/MAG/WHT
MARK
0/20000
0/20000
OWN TRACK
TGT TRACK*
0/15000
* Not available on IMO and A type radar.
8 MARK POS
CURSOR/OS/L/L
00 00.000 N
000 00.000 E
To Next Page
