SYSTEM CONFIGURATION
ANTENNA
UNIT
IC-119
PERSONAL
COMPUTER
(Windows OS)
COMMUNICATION UNIT IC-219
(with internal GPS receiver)
100-115/200-230 VAC
1φ, 50/60 Hz
: Standard supply
: Optional or
Local Supply
12/24 VDC
AC-DC
Power Supply
PR-240
JUNCTION BOX
IC-318
SSAS ALERT UNIT
IC-307*
SSAS ALERT UNIT
IC-307*
CATEGORY OF UNITS:
Unit Category
Communication Unit Protected from the weather
Antenna Unit Exposed to the weather
Other Units Protected from the weather
* At least two SSAS Alert Units
are required.
NAVIGATOR
(GNSS
compliant)
24 VDC
To Next Page
