Specifications
General
Weight 750 g (26.5 oz.)
Water resistance IEC 60529 IPX7 (front of stereo only, when properly installed)
Operating temperature range From 0 to 50°C (from 32 to 122°F)
Storage temperature range From -20 to 70°C (from -4 to 158°F)
Input voltage From 10.8 to 16 Vdc
Current (max.) 15 A
Current (muted) Less than 900 mA
Current (off) Less than 200 mA
Fuse 15 A mini blade-type
NMEA 2000 LEN @ 9 Vdc 1 (50 mA)
Bluetooth wireless range Up to 10 m (30 ft.)
ANT wireless range Up to 3 m (10 ft.)
Wireless frequencies/protocols
Wi‑Fi 2.4 GHz @ +15 dBm nominal
Bluetooth 2.4 GHz @ +10 dBm nominal
ANT 2.4 GHz @ +4 dBm nominal
Compass-safe distance 15 cm (5.9 in.)
On-board, Class D Amplifier
Output music power per channel 4 x 70 W max. 2 ohm
Total output peak power 280 W max.
Output power per channel
1
4 x 43 W RMS at 14.4 Vdc input, 2 ohm, 10% THD
4 x 26 W RMS at 14.4 Vdc input, 4 ohm, 10% THD
Line output level (max.) 5.5 V (peak to peak)
Aux input level (typical) 1 V RMS
Tuner frequencies
Tuner Europe and Australasia USA Japan
FM radio frequency range 87.5 to 108 MHz 87.5 to 107.9 MHz 76 to 95 MHz
FM frequency step 50 kHz 200 kHz 50 kHz
AM radio frequency range 522 to 1620 kHz 530 to 1710 kHz 522 to 1620 kHz
AM frequency step 9 kHz 10 kHz 9 kHz
1
The stereo may limit the output power to prevent the amplifier from overheating, and to maintain the audio dynamics.
Appendix 39
