FUTABA 10J - Page 142

142
Helicopter
■ Activatingthefunction（R.P.MCH
selection）
＋ −
or
①Selectthe"MIX"item
andthenselectthe
"CH7""CH8"or"CH9"by
pressingthe+keyor‒
key.
● Whenyoudonotuseafunction,settothe
"INH"side.
■ Switchselection
＋ −
or
②Selectthe"MODE"
itemandthenselect
theswitchby pressing
the+keyor‒key.
Range：Cond,SwA 〜 SwH
■ R.P.Mset
＋ −
or
ting
③ Selectthe"RATE"item
andthenadjusttherate
bypressingthe+keyor‒
key.
Range：0.0 〜 100.0%
Default：
（Cond）
NORM=0.0%,IDL1=50.0%,IDL2=100.0%,
IDL3=100.0%,HOLD=0.0%
（2PSwitchselection）
UP=0.0%,DOWN=100.0%
（3PSwitchselection）
UP=0.0%,CNTR=50.0%,DOWN=100.0%
（WhenusinganON/OFFswitch）
*SelecttheOFF-CTRLitemandthenadjusttheratebypressingthe+keyor‒key.
■ ON/OFFSwitchselection
＋ −
or
①Selectthe"SW"
itemandthen
selecttheswitch
bypressingthe
+keyor‒key.
Range：SwA 〜 SwH
Default：SwA
■ Switchdirection
＋ −
or
② Selectthe"POSI"bypressing
the+keyor‒keyattheON
directionselectionitem.
● 2PSW：UP,DOWN
● 3PSW：UP,UP&D,UP&C,CNTR,C&DN,DOWN
（WhennumberofrotationsgoesupatthetimeofThrottlehold）
*Ifthespeedisincreasedatthrottlehold,thegovernorandtransmitteroperatingdirectionswillnot
coincide.Inthiscase,matchtheoperatingdirectionsbyreversingthepolarityof"CH8".
Governormixing
Whatisagovernor ？
Agovernorismadeupofasetofsensorswhich
readtheRPMofthehelicopterʼ shead,anda
controlunitthatautomaticallyadjuststhethrottle
settingtomaintainaconstantheadspeed
regardlessofchangesinpitchofblades,weather
conditions,etc.Governorsareextremelypopularin
competitionhelicoptersduetotheconsistency
provided.
Howdoesithelpinhelicoptersetup?The
governoreliminatestheneedtospendlarge
amountsoftimesettingupthrottlecurves,asit
automaticallyadjuststheengineʼ sRPMto
maintainthedesiredheadspeed.
