FUTABA 10J - Page 90

90
Commonfunction
ID=[ID]
DisplaystheIDoftheservowhoseparametersaretoberead.Itcannotbechanged.
CHAN▶[Channel]
ChanneloftheS.BUSsystemassignedtotheservo.Alwaysassignachannelbeforeuse.
NEUT▶[NeutralOffset]
Theneutralpositioncanbechanged.Whentheneutraloffsetislargevalue,theservo'srange
oftravelisrestrictedononeside.
EPA▶[TravelAdjust]
Theleftandrighttravelscenteredabouttheneutralpositioncanbesetindependently.
DEAD▶[Deadband]
Thedeadbandangleatstoppingcanbespecified.
[Relationshipbetweendeadbandsetvalueandservooperation]
Small
ĺ
Deadbandangleissmallandtheservoisimmediatelyoperatedbyasmallsignal
change.
Large
ĺ
Deadbandangleislargeandtheservodoesnotoperateatsmallsignalchanges.
(Note)Ifthedeadbandangleistoosmall,theservowilloperatecontinuouslyandthe
currentconsumptionwillincreaseandthelifeoftheservowillbeshortened.
REVE▶[Reverse]
Thedirectioninwhichtheservorotatescanbechanged.
STRE▶[Stretcher]
Theservoholdcharacteristiccanbeset.Thetorquewhichattemptstoreturntheservotothe
targetpositionwhenthecurrentservopositionhasdeviatedfromthetargetpositioncanbe
adjusted.
Thisisusedwhenstoppinghunting,etc.,buttheholdingcharacteristicchangesasshown
below.
[Relationshipbetweenstretcherandservooperation]
Small
ĺ
Servoholdingforcebecomesweaker.
Large
ĺ
Servoholdingforcebecomesstronger.
(Note)Whenthisparameterislarge,thecurrentconsumptionincreases.
S.BUS Servo Description of function of each parameter
*Thereareafunctionwhichcanbeusedaccordingtothekindofservo,andanimpossible
function.
