23
Before Using
LCD Screen and Edit Keys
When the transmitter power switch is turned on, the model memory No. and model
name currently called are temporarily displayed for confirmation.
Turn on the power switch
A tone will sound to
show that the power is
on.
Model No. (1~8)After the model No. is
displayed for about one
second, the LCD will
switch to the model
name display.
After the model name is
displayed for several
seconds, the LCD will
switch to the timer and
voltage display.
Model name (6 characters)
D/R function rate display
ATL function rate display
Channel 3 position display
Select mode menu
PCM/PPM display
Steering trim display
RF output monitor
Throttle trim display
Channel selection display
Total time display
(Hours : Minutes)
Battery voltage display
To Next Page
