FUTABA 3PJ Super - Receiver and Servo Connections

27
Installation
1
2
3
B/C
1
2
3
B/C
-
+
FET amp
Ni-cad battery
Motor
Steering servo
Steering servo
Throttle servo
Channel 3 servo
Receiver
Receiver
CH1
CH1
CH2
CH2
CH3
CH3
B
Receiver
switch
To receiver
battery
Installation
Receiver and Servo Connections
Installation When An FET Amp Is Used (MC510CFET Amp)
When connecting and installing the receiver and servos, read the “Installation Safety
Precautions” on the next page.
Installation For Gas Powered Models
