34
Direct Mode Functions
5. At the end of adjustment,
press the DIRECT key twice.
(Returns to the initial screen.)
- 2 times
Maximum Servo Throw
The steering ATV function determines the steering servo maximum travel. However,
when the functions below are adjusted, the maximum travel may exceed the travel
range set by the ATV function. Any time adjustments are made to the following
functions, check you linkage installation.
- Steering subtrim
- Programmable mixing (When steering set to slave side)
- Tilt mixing
Note
When D/R is 100%, and the servo throw is insufficient even when ATV is increased
to 120%, the servo throw can be increased somewhat by using the programmable
mixing function. (See page 84.)
DIRECT ST.EXP M.SEL
UP
+
SETUP RESET
SELECT DOWN
-
TH.EXP ATV CUSTOM
