FUTABA 3PJ Super - Page 50

50
Select Mode Functions
4 Adjust the steering servo
RETN direction delay with the
+ or - key.
(The TURN direction setting
is not affected.)
- Return to the initial value (100%)
by pressing the + and - keys si-
multaneously for about one sec-
ond.
5 At the end of adjustment.
press the DOWN key twice,
or press the DIRECT key
twice. (The display returns to
the initial screen.)
- 2 times
Setting example (Steering servo: S9402) . . . (Setting criteria)
- Onroad TURN side: Approx. 50~80% RETN side: Approx. 60~100%
- Offroad TURN side: Approx. 70~100% RETN side: Approx. 80~100%
Affect on each direction
- When the TURN direction is set, the RETN direction setting also changes.
- When the RETN direction is set, the TURN direction setting is not affected.
DIRECT ST.EXP M.SEL
UP
+
SETUP RESET
SELECT DOWN
-
TH.EXP ATV CUSTOM
DIRECT ST.EXP M.SEL
UP
+
SETUP RESET
SELECT DOWN
-
TH.EXP ATV CUSTOM
