22
Before Using
Throttle stick function Steering stick function
Left turn
Left
Right turn
Right
ForwardUP
Down brake or back
(
RC Car example shown
）
Servo operation of steer-
ing channel (CH1)can be
checked.
Servo operation of throt-
tle channel (CH2) can be
checked.
Throttle stick
CH2
Steering stick
CH1
Stick Operation CH1 CH2
(CH1: Steering stick, CH2: Throttle stick,)
Throttle Stick Function: Controls the speed of the model as well as the direction of travel
- forward or reverse.
Steering Stick Function: Turns the model right or left.
