0
Normal
+1 ~ +100
Stick operation
Faster
-1 ~ -100
Gentler
Servo travel
Vertical cursor moves in step
with throttle stick operation.
*This function is not available in "TH-STK : F10 mode"
61
Fun ction
Exponential Adjustment "EXP"
(Preparation)
- On the EXP screen make the following adjustments:
1
Select the setting item "BRK" using the (JOG) button up or
down operation.
Use the (+) button to adjust for a faster initial throttle re-
sponse or use the (-) button for a gentler throttle response.
Throttle brake side EXP adjustment
Adjustment range
-100 ~ 0 ~ +100%
Adjust button
Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
The steering and throttle EXP adjustment (RATE) can be controlled with digital dial
or digital trim with the function select
switch dial
function.
Dial / Trim Setting
2
When completed, return to the MENU1 screen by pressing
the (JOG) button.
To Next Page
