86
From 5/7
Go to 7/7 from any
cursor position
(14) Speed Comp: Speed compensation
In 120 degrees CCPM all servos do not travel the same distance on
elevator input. Having previously set the ELE-PIT and ELE-AIL param-
eters, if during rapid movement of the elevator axis the swash plate is
not staying level, use the [
/+] or [ /-] key to match all servo speeds.
Note: a (+ will slow the Aileron/Pitch Servo – will reduce speed comp on
Aileron/Pitch Servo).
Setting ranges: 0 ~ 100% Initial value: H3-120 = 50%, except H3-120 = 0%
(15) SWASH Rot: Swash rotation
Using the [ /+] or [ /-] key, electronically add rotor head phasing to the
swash plate controls. If possible, it is recommended to use mechanical
phasing adjustment, but if the rotor head does not allow this and you feel
that the model is NOT flying axially on each control input, this parameter
can be used to adjust the pure reaction of each axis in flight. (Typi-
cally advanced phasing on clockwise rotor disk and a slight clockwise
increase in swash plate alignment vs rotor axle are needed to create
an axial reaction. The opposite is true for a counterclockwise rotor disk
model.)
Setting ranges: -90
deg ~ +90
deg Initial value: +0
deg
SWH. DETAIL screen 6/7
