98
: :
:
SBUS SERVO screen 1/4
From 4/4 From the "BUZZER" of
SBUS SERVO screen 4/4
ID
Displays the ID of the servo whose parameters are to be read.
It cannot be changed.
Description of function of each parameter
With some S.BUS(2) servos, there are some functions which cannot be used.
If a function cannot be used, the display screen will change.
Go to 2/4 from any cursor position
(1) CH
Channel of the S.BUS system assigned to the servo. Always assign a
channel before use.
Note: Since servo with servo type set to 760
μS (DG: 760) can not be used as S.
BUS system, CH setting can not be selected.
(2) Servo Type
This function changes 760
μS type and 1520
μS type. (Only S.BUS servo
that can be changed)
